1.6 Components of a servo system
SERVOSTAR
®
601...620 Installation Manual 17
Kollmorgen 03/04 General
24V supply
fuses
drive contactor
terminals
motor
SERVOSTAR 600
PC
Control / PLC
Option -AS-
