4.3 Error messages
Errors which occur are shown in coded form by an error number in the LED display on the front
panel. All error messages result in the BTB/RTO contact being opened, and the output stage of the
amplifier being switched off (motor loses all torque). If a motor-holding brake is installed, it will be
activated.
Number Designation Explanation
F01*
heat sink temperature
heat sink temperature too high
limit is set by manufacturer to 80°C (176°F)
F02*
overvoltage
overvoltage in DC-link
limit depends on the mains supply voltage
F03*
following error message from the position controller
F04
feedback cable break, short circuit, short to ground
F05*
undervoltage
undervoltage in DC-link
limit is set by manufacturer to 100V
F06
motor temperature
motor temperature too high
limit is set by manufacturer to145°C (293°F)
F07
aux. voltage internal aux. voltage not OK
F08*
overspeed motor running away, speed is too high
F09
EEPROM checksum error
F10
Flash-EPROM checksum error
F11
brake cable break, short circuit, short to ground
F12
motor phase motor phase missing (cable break or similar)
F13*
internal temperature internal temperature too high
F14
output stage fault in the output stage
F15
I²t max I²t max. value exceeded
F16*
supply - BTB/RTO 2 or 3 phases missing in the supply feed
F17
A/D converter
error in the analog-digital conversion, usually caused by excessive
EMI
F18
regen regen circuit faulty or incorrect setting
F19*
supply phase
a supply phase is missing
(can be switched off for 2-phase operation)
F20
Slot fault Hardware fault of the expansion card
F21
Handling fault Software fault of the expansion card
F22
Short circuit to earth
(ground)
SERVOSTAR 640/670 only: short circuit to earth (ground)
F23
CAN Bus off CAN Bus total communication error
F24
Warning Warning displays as error
F25
Commutation error Encoder systems only
F26
Limit switch Homing error (hardware limit switch reached)
F27
AS-option Operating error for AS-option
F28
reserved reserved
F29
SERCOS SERCOS error
F30
Emerg. Stop Timeout Emerg. Stop Timeout
F31
reserved reserved
F32
system error system software not responding correctly
* = These error messages can be cancelled by the ASCII command CLRFAULT, without executing a reset. If
only these errors are present, and the RESET button or the I/O-function RESET is used, the CLRFAULT com
-
mand is also all that is carried out.
60 SERVOSTAR
®
601...620 Installation Manual
Setup 03/04 Kollmorgen
