Kollmorgen SERVOSTAR 601 Assembly And Installation Guide

5.9 Accessories
5.9.1 External 24V DC / 5A supply
Technical data
Input voltage 120 / 230V
Input current 0,9 / 0,6A
Frequency 50/60Hz
Primary fuse 3,15AT
Output voltage 24V ± 1%
Max. output current 5A
Residual ripple <150mVss
Switching peaks <240mVss
Output fuse short circuit proof
Temperature range 0...+60°C (140°F)
Type of mounting
DIN-rails, vertical mounting
Keep a clear space of 50mm above and below the instrument
Weight 0,75kg
86 SERVOSTAR
®
601...620 Installation Manual
Extensions / Accessories 03/04 Kollmorgen
