Installing and Setting up the Machine > Part Names

Connectors/Interior

1 LINE Connector

2 TEL Connector

3 Option Interface

4 Network Interface Connector

5 USB Interface Connector

6 Envelope Lever

7Fuser Cover

8 Paper Width Guides

9 Support Tray Section of the Multi Purpose Tray

10 Multi Purpose Tray

11 Paper Length Guide

12 Paper Width Guides

13 Bottom Plate

14 Size Dial

15 Duplex Cover
