10-25
Troubleshooting > Troubleshooting
Clearing Paper Jams
If a paper jam occurs, [Paper jammed] appears in the message display and the machine will stop. This section explains
the procedures to remove the jammed paper.
Jam Location
Detailed paper jam positions are as follows.
After you remove the jam, the machine will warm up again and the error message will be cleared. The machine resumes
with the page that was printing when the jam occurred.
Paper Jam Location Indicator Paper Jam Location Reference Page
A
Multi Purpose Tray page 10-26
B
Cassettes 1 to 5 page 10-27
C
Duplex Unit page 10-28
D
Inside the Machine page 10-29
E
Inner Tray / Inside Rear Cover page 10-30
F
Document Processor page 10-31
To Next Page
