Kyocera FS-2020D Service Manual

2J0/2J1/2J2-4
2-3-6
YC506 1 FUSER-L I 2 to 5 V DC Envelope switch-L setting detection voltage (4 levels)
Connected
to the fuser
unit
2 FUSER-R I 02 to 5 V DC Envelope switch-R setting detection voltage (4 levels)
3 +5V1 O 5 V DC 5 V DC power source
4 THERM3 - - Not used
5 +5V2 O 5 V DC 5 V DC power source
6 EXITPAP I 0/5 V DC Paper exit sensor: On/Off
7 GND - - Ground
8 THERM1 I Analog Fuser thermistor 1 detection voltage
9 +5V1 O 5 V DC 5 V DC power source
10 FDDRN O 0/24 V DC Face up/down solenoid * : On/Off
11 +24V2 O 24 V DC 24 V DC power source
12 FUDRN O 0/24 V DC Face up/down solenoid * : On/Off
13 +5V2 O 5 V DC 5 V DC power source
14 DUPAP I 0/5 V DC Duplex sensor*: On/Off
15 GND - - Ground
16 +5Vy1 O 5 V DC 5 V DC power source
17 THERM2 I Analog Fuser thermistor 2*detection voltage
YC7 1 GND - - Ground
Connected
to the lift
sensor*
2 LIFTSEN I 0/5 V DC Lift sensor*: On/Off
3 +5V2 O 5 V DC 5 V DC power source
YC9 1 WETCLK2 O 0/5 V DC (pulse) Temperature/humidity detection sensor clock signal
Connected
to the con-
nect-R PWB
(YC1)
I Analog and detection voltage (humidity)
2 WETCLK1 O 0/5 V DC (pulse) Temperature/humidity detection sensor clock signal
3 +5V1 O 5 V DC 5 V DC power source
4 AIRTEMP I Analog Temperature/humidity detection sensor detection
voltage (temperature)
5 RFANDRN O 0/12/24 V DC Right fan motor: Full speed/Half speed/Off
6 +24V1 O 24 V DC 24 V DC power source
7 MPFDRN O 0/24 V DC MP tray paper feed solenoid: On/Off
8 OUTB3 O 0/24 V DC (pulse) Switchback motor drive pulse
9 OUTB1 O 0/24 V DC (pulse) Switchback motor drive pulse
10 OUTA3 O 0/24 V DC (pulse) Switchback motor drive pulse
11 OUTA1 O 0/24 V DC (pulse) Switchback motor drive pulse
12 GND - - Ground
YC11 1 +24V4 O 24 V DC 24 V DC power source
Connected
to the drum
motor
2 GND - - Ground
3 DMOTRDYN I 0/5 V DC Drum motor ready signal
4 DMOTCLK O 0/5 V DC (pulse) Drum motor clock signal
5 DMOTONN O 0/5 V DC Drum motor: On/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
