Kyocera FS-2020D Service Manual

2J0/2J1/2J2
2-3-7
*: 40/42 and 45/47 ppm printers (EUR/USA model) only.
YC12 1 POLRDYN I 0/5 V DC Polygon motor ready signal
Connected
to the main
PWB
2 POLONN O 0/5 V DC Polygon motor: On/Off
3 OUTPEN O 0/5 V DC Print data output enable signal
4 PDMASKN O 0/5 V DC PD mask control signal
5 SBSY O 0/5 V DC Engine busy signal
6 SDIR O 0/5 V DC Communication direction change signal
7 EGIRN O 0/5 V DC Engine interrupt signal
8 EGSI I 0/5 V DC (pulse) Main PWB serial communication data signal input
9 EGSO O 0/5 V DC (pulse) Main PWB serial communication data signal output
10 SCLKN O 0/5 V DC (pulse) Main PWB serial communication clock signal
11 RESETN O 0/5 V DC Reset signal
12 +24V5 O 24 V DC 24 V DC power source
13 +5V1 O 5 V DC 5 V DC power source
14 +5V1 O 5 V DC 5 V DC power source
15 GND - - Ground
16 +5V1 O 5 V DC 5 V DC power source
17 GND - - Ground
18 GND - - Ground
19 GND - - Ground
20 +24V4 O 24 V DC 24 V DC power source
YC15 1 +5V1 O 5 V DC 5 V DC power source
Connected
to the feed
fan motor
2 FANDRN O 0/2.5/5 V DC Feed fan motor: Full speed/Half speed/Off
Connector Pin Signal I/O Voltage Description

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
