Kyocera FS-2020D Service Manual

2J0/2J1/2J2-5
1-3-12
Service items Description
No. Items Description
 Paper Jam Log # Count. Event
Remembers 1 to 16 of occur-
rence. If the occurrence of
the previous paper jam is
less than 16, all of the paper
jams are logged. When the
occurrence excessed 16, the
oldest occurrence is
removed.
The total page
count at the time
of the paper
jam.
Log code (2 digit, hexadecimal,
5 categories)
(a) Cause of a paper jam
(b) Paper source
(c) Paper size
(d) Paper type
(e) Paper exit
(a) Cause of paper jam
10: Paper does not arrive at the registration sensor. [42] (MP tray)
10: Paper does not arrive at the registration sensor. [31] (Printer’s cassette)
10: Paper does not arrive at the registration sensor. [31] (Paper feeder 1)
10: Paper does not arrive at the registration sensor. [31] (Paper feeder 2)
10: Paper does not arrive at the registration sensor. [31] (Paper feeder 3)
10: Paper does not arrive at the registration sensor. [49] (Duplex conveying)
10: Paper does not arrive at the registration sensor. [4A] (Bulk paper feeder)
10: Paper does not arrive at the registration sensor. [31] (Envelope feeder)
11: Paper does not pass the registration sensor. [48]
12: Paper remains at the registration sensor when power is turned on. [48]
20: Paper does not arrive at the paper exit sensor. [48]
21: Paper does not pass the paper exit sensor. [47]
22: Paper remains at the paper exit sensor when power is turned on. [47]
30: Paper does not arrive at the paper feeder 1’s paper feed sensor. [32]
(Paper feeder 1)
30: Paper does not arrive at the paper feeder 1’s paper feed sensor. [33]
(Paper feeder 2)
30: Paper does not arrive at the paper feeder 1’s paper feed sensor. [33]
(Paper feeder 3)
31: Paper does not pass the paper feeder 1’s paper feed sensor. [32]
32: Paper remains at the paper feeder 1’s paper feed sensor when power is turned
on. [32]
40: Paper does not arrive at the paper feeder 2’s paper feed sensor. [33]
(Paper feeder 2)
40: Paper does not arrive at the paper feeder 2’s paper feed sensor. [34]
(Paper feeder 3)
41: Paper does not pass the paper feeder 2’s paper feed sensor. [33]
42: Paper remains at the paper feeder 2’s paper feed sensor when power is turned
on. [33]
50: Paper does not arrive at the paper feeder 3’s paper feed sensor. [34]
(Paper feeder 3)
51: Paper does not pass the paper feeder 3’s paper feed sensor. [34]
52: Paper remains at the paper feeder 3’s paper feed sensor when power is turned
on. [34]
A1: Paper does not arrive at the duplex sensor. [47] (Rear unit)
A2: Paper does not pass the duplex sensor. [47] (Rear unit)
A3: Paper does not arrive at the duplex jam sensor. [49] (Duplex conveying)
A4: Paper does not pass the duplex jam sensor. [49] (Duplex conveying)
A5: Paper remains at the duplex jam sensor when power is turned on. [49]

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
