Kyocera FS-2020D Service Manual

2J0/2J1/2J2
1-4-3
0420 Paper feeder communication error
Communication error between engine
PWB and optional paper feeder.
Improper installa-
tion paper feeder.
Follow installation instruction carefully again.
Defective harness
between connect-L
PWB (YC2) and
paper feeder inter-
face connector, or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective harness
between connect-L
PWB (YC6) and
engine PWB
(YC504), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
Defective paper
feeder.
Replace the paper feeder.
1010 Lift motor lock error
*40/42 and 45/47 ppm printers (EUR/
USA model) only
A motor over-current signal is detected
continuously for 5 seconds since the lift
motor is activated.
Defective bottom
plate elevation
mechanism in the
paper cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Defective lift motor
drive transmission
system.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective lift motor. Replace the lift motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
1140 Lift motor ascent error
*40/42 and 45/47 ppm printers (EUR/
USA model) only
Optional bulk paper feeder’s tray top
position sensor does not turn on.
Lift motor lock error occurred 3 times.
Defective bulk
paper feeder’s tray
top position sensor.
Replace the bulk paper feeder’s tray top
position sensor.
Defective harness
between bulk
paper feeder’s tray
top position sen-
sor and main PWB
(YC6), or improper
connector inser-
tion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective bulk
paper feeder’s
main PWB.
Replace the bulk paper feeder’s main PWB.
(Refer to bulk paper feeder’s service man-
ual)
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
