Kyocera FS-2020D Service Manual

2J0/2J1/2J2
1-4-4
1150 Lift motor descent error
*40/42 and 45/47 ppm printers (EUR/
USA model) only
Optional bulk paper feeder’s tray bottom
position sensor does not turn on.
Lift motor lock error occurred 3 times.
Defective bulk
paper feeder’s tray
bottom position
sensor.
Replace the bulk paper feeder’s tray bottom
position sensor.
Defective harness
between bulk
paper feeder’s tray
bottom position
sensor and main
PWB (YC8), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness. (Refer to
bulk paper feeder’s service manual)
Defective bulk
paper feeder’s
main PWB.
Replace the bulk paper feeder’s main PWB.
(Refer to bulk paper feeder’s service man-
ual)
2000 Main motor error
MMOTRDYN signal does not go low
within 2 s after MMOTONN signal goes
low.
Defective harness
between main
motor and engine
PWB (YC501), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective main
motor drive trans-
mission system.
Check if the rollers and gears rotate
smoothly. If not, grease the bushings and
gears. Check for broken gears and replace if
any.
Defective main
motor.
Replace the main motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
2200 Drum motor error
DMOTRDYN signal does not go low
within 2 s after DMOTONN signal goes
low.
Defective harness
between drum
motor and engine
PWB (YC11), or
improper connec-
tor insertion.
Reinsert the connector. Also check for conti-
nuity within the connector harness. If none,
remedy or replace the harness.
Defective drum
motor drive
transmission
system.
Check if the gears rotate smoothly. If not,
grease the bushings and gears. Check for
broken gears and replace if any.
Defective drum
motor.
Replace the drum motor.
Defective engine
PWB.
Replace the engine PWB (See page 1-5-
25).
Code Contents
Remarks
Causes Check procedures/corrective measures

Kyocera FS-2020D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Memory type	DDR2
Processor model	PowerPC 440
Maximum internal memory	1152 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	52 dB
Power supply type	220/240 V, 50/60 Hz
Capacity cartridge	12000 sheets
Power consumption (active)	560 W
Recommended monthly print volume	20000 pages
Maximum duty cycle	150.000 pages per month
Number of print cartridges	1
Total input capacity	500 sheets
Total output capacity	250 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	9.2 W
Power consumption (PowerSave)	5.7 W
Energy Star Typical Electricity Consumption (TEC)	2.6 kWh/week
Display	LCD
Certification	GS, TüV, CE
Standard interfaces	Parallel, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	382 x 394 x 285 mm
