Kyocera FS-2020D - Page 86

2J0/2J1/2J2
1-5-28
18. Remove four screws.
Figure 1-5-37
19. Detach the engine PWB assembly.
20. Remove four connectors.
21. Remove the engine PWB assembly.
Figure 1-5-38
Screw
Screw
Screw
Screw
Connectors
Engine PWB assembly
Connectors
