2J0/2J1/2J2
1-5-34
13. Remove one connector.
14. Remove six screws and then remove the
power source PWB.
15. Check or replace the power source PWB
and refit all the removed parts.
Figure 1-5-46
Screw
Screw
Screws
Screws
Heat sink plate
Screw
Power source PWB
Power source PWB plate
Connector
