Installing and Setting up the Machine > Part Names (With Optional Equipments Attached)

Part Names (With Optional Equipments

Attached)

1 Tray 1 to 5 (tray 1 is the top tray)

2Tray A

3Tray B

4 Inner Tray

5 Finisher Tray

Optional Equipment (page 11-2)

6 Cassette 2

7 Cassette 3

8 Cassette 4

9 Job Separator Tray

10 Control Section of the Finisher

Manual Staple (page 5-69)
