1.1 Optional extras
1.1.1 Extension kit for 500 mm film
This extension kit changes the rotation speed of the wrapping table rollers to
handle film rolls with a width of 500 mm. The extension kit consists of a gear
wheel and a drive chain extension. The gear wheel is replaced with the
standard gear wheel to change the rotation speed of the wrapping table
rollers for correct overlap of the film layers. The drive chain is extended to fit
the new gear wheel setting.
1. Gearwheel - 2. Chain (incl. 3. Master link)
Figure 3. Extension kit for 500 mm film
Introduction
1-3
W-H003.1403EN
