1.1.3 Suction cup
The suction cup mount assembly can be attached to any non-porous
surface. The suction pad holds the assembly against the surface based on
vacuum. The crank lever creates a vacuum to hold or loosen the mounting
position. The bracket is used to mount the Eālink manual controller.
1. Suction cup - A. Loose - B. Hold
Figure 5. Suction cup mount assembly
