3.5 Move the Attis to the transport position
Make sure there are no persons in the area when you move the Attis to
the transport position.
Use all lights and warning signals as defined by your local road traffic
regulations.
Always switch off the tractor engine and remove the ignition key before
you leave the tractor cab.
Procedure
1. Lower the loading arm (Figure 15, page 3‑15) to the ground
until the transport wheel is clear from the ground
down
2. Remove the R-clip from the wheel pin.
3. Remove the wheel pin.
4. Turn the transport wheel 180º clockwise to the inner position
(Figure 16, page 3‑16).
5. Install the wheel pin and lock it with the R-clip
6. Make sure the wrapping table is in the loading position.
6. Move the loading arm in the raised position.
up
7. Switch off the E-link manual controller.
push
8. Install the transport lock pin to secure the loading arm in the
transport positions.
9. Switch off the hydraulic of the tractor.
10. If the bale end-tripper is available:
a. Loosen the locking pins to release the transport lock
(Figure 17, page 3‑17) from the storage position.
b. Move the bale end-tripper from the working position to
the transport position.
c. Position the transport lock in the transport position.
d. Lock the transport lock with the locking pins in the
transport position.
WARNING
CAUTION
WARNING
3-14 Operation
W-H003.1403EN
