7. DIAGRAMS AND TABLES
7.1 Bolt and nut torque table
The following tables specify the standard torque load for all quality bolts on
the Attis.
Always use a calibrated torque wrench when you torque-tighten bolts and
nuts.
Thread size M6 M8 M10 M12 M14 M16 M20 M24
Bolt quality 8.8 8.8 8.8 8.8 8.8 8.8 8.8 8.8
Nut quality 8 8 8 8 8 8 8 8
Nm 10 25 50 85 135 215 410 710
kgm 1.0 2.5 5.0 8.5 13.5 21.5 41.0 71.0
Thread size M8 M10 M12 M14 M16 M20
Bolt quality 10.9 10.9 10.9 10.9 10.9 10.9
Nut quality 10.9 10.9 10.9 10.9 10.9 10.9
Nm 35 70 110 190 295 580
kgm 3.5 7.0 11.0 19.0 29.5 58.0
Thread size M12
Bolt quality 12.9
Nut quality 10.9
Nm 75
kgm 7.5
Wheel Nut M18x1,5
Nm 27
kgm 2.7
Diagrams and tables 7-1
