3.2.2 Start up screens
Procedure
Switch on the E-link by twisting the knob and after a few
seconds the start up screen of the main menu is
shown (page 3‑6).
00.00
◄ ▼
3.2.3
Main menu
The main menu is divided into six screens and is used during operations to:
• set the number of wraps to complete a wrapped bale.
• set/reset the field counter.
• view the number of wraps/target number of warps, field count, part count,
total count, bales per hour, rotation speed of table in rpm.
The second calibration menu (CAL.2) (page 3‑9) and the third calibration
menu (CAL.3) (page 3‑11) are only applicable for Lely personnel and
service engineers. The screens of the menus are used to change the
settings and the behaviour of the Attis.
Use the quick references chart (page 7‑4) to understand the menu
structure of the following functions.
3.2.3.1 NORMAL (screen 1) default
The Normal screen shows the current wraps in relation to the preset target
wraps. The first and second digit show the current wraps (Current) and the
third and fourth digit show the target wraps (Prog.). The values Current and
Prog. can be stored to 100 numbers (00...99).
Select a field
1. Activate this menu to define the target wrap rotations
Hold this button to the end of this procedure.
hold
2 Cycle through the code (0-9) to select the first digit code.
Hold the button until the correct value is shown.
hold
3. Save the selected first digit and go to the next digit.
release
4. Cycle through the code (0-9) to select the second digit code.
Hold the button until the correct value is shown.
hold
5. Save the selected second digit.
release
6. If the first digit and second digit are:
Note:
00.00
◄ ▼
3-6 Operation
W-H003.1403EN
