8. SPECIFICATIONS
8.1 Attis PT 130 Specifications
Transport width 2.53 m (99.60 inch)
Transport length 4.70 m (185.03 inch)
Transport height 2.30 m (90.55 inch)
Maximum bale diameter 0.90 - 1.30 m (35,5 - 59.05 inch)
Maximum bale width 1.25 m (49.21 inch)
Maximum bale weight 1000 kg (2200 lbs)
Tyre size 10.0/75x15.3 (... bar)
Linkage Pin hitch
Hydraulic connections 1 single acting valve, free return
Hydraulic flow 30 litre/min at 150 bar (2176 psi)
Maximum speed wrapping table 30 rpm
Maximum speed 40 km/h
Power requirement 30 kW
Approximate weight 1080 kg (2376 lbs)
Film stretch 55%/70%
Film width 750 mm ( 29.52 inch) and optional 500 mm
(19.68 inch)
Electric requirement 12 Volt DC
All specifications may be changed without prior notice.
Note:
Specifications 8-1
W-H003.1403EN
