4.5 Adjust the bale end-tipper
Procedure:
1. Verify if the bale end-tripper is level in the working position:
Use a levelling instrument (2) to level the bale end tipper. If not, then
tighten or loosen the nut (1), the tension on the spring, till the bale
end-tripper is level in the working position.
1. Nut - 2. Levelling instrument
Figure 30. Adjust the bale end-tipper
Operation adjustments
4-7
W-H003.1403EN
