5.2.2 Lubricate the drive chain of the wrapping table rollers
• Requirements:
• Oil can
• GX85-W140 transmission oil or equivalent
Stop the tractor engine and remove the ignition key from the tractor
before you do maintenance or adjustments to the Attis.
1. Remove the two bolts from the drive chain housing.
2. Remove the drive chain housing.
3. Lubricate the drive chain of the wrapping table rollers by using an oil
can.
4. Install the drive chain housing.
5. Install the two bolts to the drive chain housing.
B. 100 hours
1. Chain box cover - 2. Nut and washer- 3.Drive chain (B)
Figure 34. Lubricate the drive chain of the wrapping table rollers
WARNING
5-8 Maintenance
W-H003.1403EN
