Grease the gearwheels of the transmission
Requirements:
• Molykote BR2 Plus or equivalent
Stop the tractor engine and remove the ignition key from the tractor
before you do maintenance or adjustments to the Attis.
Procedure
1. Remove the three bolts from the gearbox cover on right side of the
Attis.
2. Open the gearbox by sliding the cover plate to the right.
3. Apply grease to the gearwheels.
4. Close the gearbox by sliding the cover plate to the left.
5. Insert and tighten the bolts to secure the cover plate of the gearbox.
B = 100 hours
1. Bolt - 2. Gearbox cover plate 3. Gearwheels (B) - 4. Grease
Figure 33. Grease the gearwheels
WARNING
Maintenance 5-7
W-H003.1403EN
