11. Move the wrapping table to the top position until it stops,
while the film is cut and the bale is unloaded to the ground.
hold up
12. Move the wrapping table to the bottom position.
When the wrapping table has reached the bottom position, it
turns automatically to the loading position to receive the next
bale.
down
1. Loading arm (including bale stop)
Figure 20. Load bale on loading arm to bale stop
Operation
3-23
W-H003.1403EN
