Lexmark MS510 - Speaker and Control Panel USB Port Removal (Ms610 De)

5 Remove the two screws (A), and then remove the control panel USB port.
A
Speaker and control panel USB port removal (MS610de)
1 Remove the right cover. See “Right cover removal” on page 194.
2 Remove the nameplate. See “Nameplate removals” on page 216.
3 Remove the bezel. See “Bezel removals” on page 214.
4 Remove the control panel assembly. See “Control panel assembly removals” on page 218.
5 Remove the three screws (A), and then remove the speaker and control panel USB port.
A
4514-6xx
Repair information
226
