Lexmark MS510 - Assembly 6: Maintenance Kits

Assembly 6: Maintenance kits
Asm-index P/N Units/mach Units/FRU Description Removal procedure
NS 40X8439 1 1 Maintenance kit, 100 V (MS510dn and M1145)
• 100 V fuser (40X8343)
• Paper exit guide (40X8298)
• ACM pick roll (40X8297)
• Transfer roll (40X8393)
• Tray separator roll assembly (40X8444)
• MPF pick roll and separator pad (40X8295)
N/A
NS 40X8281 1 1 Maintenance kit, 110 V (MS510dn and M1145)
• 110 V fuser (40X8023)
• Paper exit guide (40X8298)
• ACM pick roll (40X8297)
• Transfer roll (40X8393)
• Tray separator roll assembly (40X8444)
• MPF pick roll and separator pad (40X8295)
N/A
NS 40X8282 1 1 Maintenance kit, 220 V (MS510dn and M1145)
• 220 V fuser (40X8024)
• Paper exit guide (40X8298)
• ACM pick roll (40X8297)
• Transfer roll (40X8393)
• Tray separator roll assembly (40X8444)
• MPF pick roll and separator pad (40X8295)
N/A
NS 40X8440 1 1 Maintenance kit, 100 V (MS610dn and M3150dn)
• 100 V fuser (40X8343)
• Paper exit guide (40X8437)
• ACM pick roll (40X8297)
• Transfer roll (40X8393)
• Tray separator roll assembly (40X8444)
• MPF pick roll and separator pad (40X8295)
N/A
NS 40X8433 1 1 Maintenance kit, 110 V (MS610dn and M3150dn)
• 110 V fuser (40X8023)
• Paper exit guide (40X8437)
• ACM pick roll (40X8297)
• Transfer roll (40X8393)
• Tray separator roll assembly (40X8444)
• MPF pick roll and separator pad (40X8295)
N/A
4514-6xx
Parts catalog
297
