9 Remove the screw (D) securing the ACM lift cam to the ACM housing.
D
10 Remove the ACM lift cam by sliding it off the shaft.
11 Remove the screw (E), and then remove the media present sensor flag.
Note: Use a #1 Phillips screwdriver.
