Lexmark MS510 - Page 288

Assembly 2: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8080 1 1 Laser scanning unit
(MS510dn and M1145)
“Laser scanning unit (LSU) removal” on
page 265
1 40X8079 1 1 Laser scanning unit
(MS610dn, MS610de,
M3150dn, and M3150)
“Laser scanning unit (LSU) removal” on
page 265
2 40X8343 1 1 Fuser, 100 V
“Fuser removal” on page 263
2 40X8023 1 1 Fuser, 110 V
“Fuser removal” on page 263
2 40X8024 1 1 Fuser, 220 V
“Fuser removal” on page 263
3 40X8050 1 1 Narrow media/bin full sensor
“Narrow media/bin full sensor removal”
on page 258
4 40X8276 1 1 Cooling fan
(MS510dn, MS610dn, M1145,
and M3150dn)
“Cooling fan removals” on page 196
4 40X9181 1 1 Cooling fan
(MS610de and M3150)
“Cooling fan removals” on page 196
5 40X8029 1 1 Controller board
(MS510dn and M1145)
“Controller board removals” on page
200
5 40X8030 1 1 Controller board
(MS610dn and M3150dn)
“Controller board removals” on page
200
6 40X8388 1 1 Controller board
(MS610de and M3150)
“Controller board removals” on page
200
7 40X7592 1 1 Tray present sensor
“Tray present sensor removal” on
page 195
8 40X8280 1 1 Front input guide
“Front input guide removal” on page
236
9 40X8300 1 1 MPF solenoid
“MPF solenoid removal” on page 184
10 40X8301 1 1 Reverse solenoid
“Reverse solenoid removal” on page
190
11 40X8285 1 1 Control panel assembly
(MS610de and M3150)
“Control panel assembly removals” on
page 218
12 40X8292 1 1 Control panel assembly
(MS510dn and M1145)
“Control panel assembly removals” on
page 218
12 40X8284 1 1 Control panel assembly
(MS610dn and M3150dn)
“Control panel assembly removals” on
page 218
4514-6xx
Parts catalog
288
