Assembly 4: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8393 1 1 Transfer roll
“Transfer roll removal” on page 210
2 40X8298 1 1 Redrive assembly
(MS510dn and M1145)
“Redrive assembly removal” on
page 260
2 40X8437 1 1 Redrive assembly
(MS610dn and M3150dn)
“Redrive assembly removal” on
page 260
2 40X8438 1 1 Redrive assembly
(MS610de and M3150)
“Redrive assembly removal” on
page 260
3 40X8850 1 1 Redrive shaft
“Redrive shaft removal” on page 261
4 40X8299 1 1 Front mounts
“Left front mount removal” on
page 206
“Right front mount removal” on
page 208
5 40X8084 1 1 Pick/Lift motor gearbox
“Pick/Lift motor gearbox removal” on
page 255
6 40X8275 1 1 Duplex assembly
“Duplex removal” on page 242
7 40X8297 2 2 Pick tires N/A
8 40X8261 1 1 ACM assembly
“ACM assembly removal” on page
253
9 40X8295 2 2 MPF pick roller and separator pad
“MPF pick roller removal” on page
230
and
“Separator pad removal” on page
238
10 40X8279 1 1 Jam access cover
“Jam access cover removal” on
page 231
11 40X8777 1 1 MPF gearbox
“MPF gearbox removal” on page 187
12 40X8277 1 1 Duplex gear assembly
“Duplex gear assembly removal” on
page 192
13 40X8083 1 1 Cartridge gearbox
“Cartridge gearbox removal” on
page 191
14 40X8085 1 1 Main drive gearbox
“Main drive gearbox removal” on
page 182
NS 40X8394 1 1 Screw kit, contains:
• MT3x0.5+8PF‑NI—10 pieces
• MT3x0.5+6PF‑NI—10 pieces
• TP2NC‑3+6PF‑NI—10 pieces
N/A
4514-6xx
Parts catalog
293
