Installation/Owner's Manual
6-14
3. When you have completed all the setting, click on the [Save] button. The ʻInformationʼ screen to ask
to save will be displayed. Click on the [Yes] button.
Item Description
Name of temperature limit operation group is displayed.
This sets the minimum to execute the temperature limit operation. The
temperature range that can be set is 1°C~16°C.
This sets the maximum temperature to execute the temperature limit
operation. The temperature range that can be set is 25°C~40°C.
Select the method to measure the indoor temperature. Indoor temperature can
be measured in one of the three methods below.
- Average: This is the method of operating the temperature limit function
based on the average temperature detected for the indoor units within the
group.
- Fixed: This is the method of operating the temperature limit function based
on the temperature detected from the first registered indoor unit within the
group.
This sets whether to execute the temperature limit operation function or not.
- Enable: Executes the temperature limit operation function.
- Disable : Does not execute the temperature limit operation function.
Group name
Low Temp.
High Temp.
Temp. reference
Enable Disable
After clicking on [Save]
button, when the
'Information' screen is
displayed, click on [Yes]
button
6. Auto control menu
To Next Page
