5 Maintenance
Engine
¾ Remove the filler cap (1) from the filling
opening.
¾ Remove cover on floor of frame.
¾ Unscrew the engine oil drain pl
ug (3)
underneath from the oil sump.
¾ Allow all oil to drain off into collection vessel.
d3921445
3
¾ Fit the drain plug (3) with a new sealing ring.
Tightening torque: 30 Nm
¾ Refit the cover (1).
Topupwithmotoroil
¾ Switch off ignition.
122 Operating Instructions – 394 807 10 01 EN – 07/2011
