5 Maintenance
Engine
¾ Open the bonnet.
¾ Remove the maintenance cover on the right
hand side.
d3921375
1
¾ Check the ribbed V-belt (1) for
signs of
excessive wear, frayed edges,
cracks
across the belt and traces of oi
l.
¾ Exchange the ribbed vee belt if it is dam-
aged.
¾ Fit maintenance panel again.
¾ Close the bonnet.
Replacing ribbed V-belt
WARNING
Do not touch rotating parts.
Switch off the engine and remove
ignition key.
NOTE
On trucks without air conditioning, first discon-
nect the ribbed V-belt from the alternator and
when reassembling, replace it last. On trucks
with air conditioning, first disconnect the rib-
bed V-belt from the guide pulley and when
reassembling, replace it last. Note the running
direction of the ribbed V-belt.
¾ Open the bonnet.
¾ Remove the maintenance cover on the
right-hand side.
136 Operating Instructions – 394 807 10 01 EN – 07/2011
