5 Maintenance
Chassis frame
Chassis frame
Changing a wheel
WARNING
Note the tare weight of the truck.
Only use jacks with a load capacity of at least
3600 kg.
CAUTION
When using wheels that are not antistatic, pay
attention to the antistatic belt.
When changing wheels that are not antistatic, the
truck must be equipped with an antistatic belt as
these wheels are not electroconductive.
The antistatic belt must always be in contact with
the ground.
Contact your authorised dealer.
¾ Position the jack at the front edge of the
chassis (2) on the left or right, or beneath
the counterweight (1).
The truck may only be raised at these lifting
points on the left and right side.
¾ Release the wheel fastenings on the wheel
in question.
¾ Raise truck with jack until wheels are off the
ground.
¾ Prop up securely using square timber
supports at the chassis or counterweight.
¾ Unscrew the wheel fastenings.
¾ Change the wheel.
¾ Position wheel fastenings and tighten them
manually.
¾ Lower truck.
¾ Tighten wheel fastenings
Front 425 Nm
Rear 640 Nm
164 Operating Instructions – 394 807 10 01 EN – 07/2011
