Linde H50D - Type Sheet H 40 Elevated Drivers Compartment, as at 07;2011

6 Technical data
Type sheet H 40 elevated driver’s compartment, as at 07/2011
Type sheet H 40 elevated driver’s compartment, as at 07/2011
All data refers to standard equipment with standard 3900 mm lift mast.
Please observe the following:
1 Identification
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H40D
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
4000
1.6
Load centre of gravity c [mm]
500
1.8 Load distance
x [mm]
483
1.9 Wheelbase
y [mm]
1998
2 Weight
2.1
Net weight kg
5995
2.2
Axle load with front/rear load
kg
8766/1229
2.3
Axle load without front/rear load
kg
2798/3197
3 wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
250-15
3.3
Rear tyre size
250-15
3.5
Number of wheels, front/rear (x = driven) 2x (4x)
25
/2
3.6 Front track width
b
10
[mm]
1221
26
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
4.0/9.0
27
4.2
Lowered mast height
h
1
[mm]
2820
28
4.3 Free lift
h
2
[mm]
150
25
Bracketed value for twin tyres.
26
The track width may deviate from the indicated value, depending on the tyre variant.
27
L
ift height and equipment may change the backwards tilt.
28
With 150 mm free lift on standard lift mast.
