Maintenance 5
Engine
¾ Open the clamps (3) on the oil bowl (2).
¾ Remove the oil bowl downwards, empty
and clean it.
¾ Clean and check ((1)) the seals
, renew if
damaged.
¾ Check the filter element ((5)) and clean if
dirty. Fill the oil bowl (2) with engine oil up to
the mark(4).
¾ Place the oil bowl (2) on the filter head (6),
check for correct seating and fasten with the
clamps (3).
Check suction and e
xhaust pipes for
leaks
¾ Check the conditi
on and tightness of the
suction air tube
s on the air filter.
If you discover leaks, re-tighten the hose clips
or change the porous pipes.
¾ Check the inlet and exhaust manifold on the
cylinder head for leaks.
If you discover
leaks, re-tighten the fixing
screws or chang
e the seals.
¾ Check the exhaust pipe connection on the
manifold for leaks. If necessary, re-tighten
the fixing screws or change the seal.
Operating Instructions – 394 807 10 01 EN – 07/2011 145
