5 Maintenance
Chassis, bodywork and fittings
¾ Undo the clamping screw (9) in the armrest
(8) and push the armrest fully downwards.
¾ Retighten clamping screw (9).
If a rear window is installed, t
he armrest
fore/aft adjustment must also
be pushed all the
way forwards. To do so, release
the clamping
screw (9), and push the armre
st (8) all the way
forwards. Retighten clampi
ng screw (9).
¾ Release the support mounting (6) by
pushing it backwards.
¾ Open bonnet (5) all the way.
NOTE
The bonnet is held in both open positions by
gas springs.
Closing the bonnet
¾ Release the support mounting (6) by
pushing it backwards.
¾ Close the bonn
et (5), then press on it until
the locking le
ver (8) engages with the
fastener (7).
Floorpla
te
Opening t
he floorplate
Some maintenance operations require that
the floorplate is lifted.
¾ Open the bonnet.
158 Operating Instructions – 394 807 10 01 EN – 07/2011
