Linde H50D - Type Sheet H 50;600, as at 07;2011

Technical data 6
Type sheet H 50/600, as at 07/2011
Type sheet H 50/600, as at 07/2011
All data refers to standard equipment with a standard 2800 mm lift mast.
Please note the following:
1 Characteristics
1.1 Manufacturer Linde
1.2
Manufacturer’s type desig
nation
H 50 D/600
1.3 Drive Diesel
1.4
Operation
Seated
1.5
Load capacity/load
Q[kg]
5000
1.6
Load centre of gravity c [mm]
600
1.8 Load distance
x [mm]
535
1.9 Wheelbase
y [mm]
2078
2 Weight
2.1
Net weight Kg
6947
2.2
Axle load with front/rear load
Kg
10,620/1327
2.3
Axle load without front/rear load
Kg
2889/4058
3 Wheels, chassis fr
ame
3.1
Front/rear tyres: polyurethane, rubber
SE (P)
3.2
Front tyre size
300-15
3.3
Rear tyre size
250–15
3.5
Number of wheels, front/rear (x = driven) 2x (4x)
19
/2
3.6 Front track width
b
10
[mm]
1190
20
3.7 Rear track width
b
11
[mm]
1122
4 Basic dimens
ions
4.1 Forward/backward fork tilt
α/β (°)
5.0/9.0
21
4.2
Lowered mast height
h
1
[mm]
2421
22
4.3 Free lift
h
2
[mm]
150
19
Bracketed value for twin tyres.
20
The track width may deviate from the indicated value, depending on the tyre variant.
21
L
ift height and equipment may change the backwards tilt.
22
With 150 mm free lift on standard lift mast.
