Linde H50D - Checking the Drive Axle Bearings for Wear; Checking the Hydraulic Pumps Mounting on the Engine

Maintenance 5
Gearbox
Checking the drive axle bearings for
wear
NOTE
The drive axle is installed in the chassis with
rubber spring elements on both sides.
¾ Remove the drive wheels.
d3941385
1
1
¾ Using a lamp, check the sta
te of the rubber
spring elements (1) betwe
en the axle,
chassis and plastic stops
.
The rubber spring elements must be checked
on both the left and right of the axle. If the axle
spring elements or the plastic stops are worn,
these must be changed. Please contact your
authorised dealer.
¾ Attach the drive wheels.
Checking the hydraulic pump’s
mounting on the engine
¾ Open the bonnet.
¾ Tighten the 3
hexagon head screws to the
specified tig
htening torque of 110 Nm.
¾ Close the bonnet.
Operating Instructions – 394 807 10 01 EN – 07/2011 155
