5 Maintenance
Engine
d3941342
1
¾ Disconnect the hose (1) from the pipe union
at the fuel signal transmitter and blow dry
compressed air through it.
¾ Slide the hose (1) onto the pipe union as far
as the stop.
Checking the cool
ant level
ENVIRONMENT NOTE
Observe information regarding working with
consumables.
NOTE
If the display (1) lights up (special equipment),
the coolant level is too low and the coolant
must be topped up. If the coolant continues to
fall below the min. mark, the truck only moves
at creep speed.
NOTE
For models without a display, (1) the coolant
level can be checked at the inspection window
(2).
CAUTION
Only use an approved coolant.
Observe the recommendations for consumables.
128 Operating Instructions – 394 807 10 01 EN – 07/2011
