6 Technical data
Type sheet H 50/500 container, as at 07/2011
4 Basic dimensions
4.7
Overhead guard height (cab) h
6
[mm]
2220
4.8
Seat height, min./max. h
7
[mm]
1151
4.12
Coupling height h
10
[mm]
733
4.19
Total length l
1
[mm]
4074
4.20
Length including fork back l
2
[mm]
3074
4.21
Overall width
b
1
/b
2
[mm]
1487/1423
53
4.22 Fork arm dimensions
s/e/l [mm]
60 x 130 x 1000
4.23
Fork carriage DIN 15173, class/form A, B
3A
4.24
Fork carriage width b
3
[mm]
1350
54
4.31
Ground clearance at mast
m
1
[mm]
146
4.32
Ground clearance at centre of wheelbase
m
2
[mm]
207
4.33
Aisle width for pallet 1000 x 1200 crosswise
A
st
[mm]
4438
4.34
Aisle width for pallet 800 x 1200 longitudinal A
st
[mm]
4638
4.35
Turning radius W
a
[mm]
2745
4.36
Smallest pivot point distance
b
13
[mm]
700
5 Performance dat
a
5.1
Driving speed with/without load
km/h 20/20
5.2
Lifting speed with/without load
m/s 0.49/0.51
5.3
Lowering speed with/without load
m/s 0.50/0.56
5.5
Pulling force with/without load
N 30202/23120
5.7
Climbing capability with/without load
%
28.0/36.0
5.9 Acceleration with/without load
s
5.8/5.1
5.10
Service bra
ke
Hydrostatic
7 Drive/engine
7.1
Engine manu
facturer/model
VW/CBJB
7.2
Engine powe
r rating as per ISO 1585
kW
55
7.3
Nominal sp
eed
rpm
2800
7.4
Number of c
ylinders/displacement
cm
3
4/1968
7.5
Fuel consumption in accordance with VDI cycle
l/h 4.5
53
The total width may deviate from the indicated value, depending on the tyre variant and fork carriage variant.
54
The fork carriage width may deviate from the indicated value, depending on the fork carriage variant.
236 Operating Instructions – 394 807 10 01 EN – 07/2011
