Overview 3
Identification plates
Nameplate
1 Nameplate
2
Manufacturer
3
Type/chassis number/year of
manufacture
4 Tare weight
5
Placeholder for "data-matrix code"
6
CE mark
7
Rated driving power
8 Rated load capacity
NOTE
The CE mark confirms compliance with the EC
machinery directive and with all regulations
applicable to the truck.
Steering axle identification plate
13
Steering axle identification plate
Operating Instructions – 394 807 10 01 EN – 07/2011 19
