3 Overview
Display unit
Display element
Function
Possible malfunctions
Remedy
(17) Operating hours display
Indicates the operating hours
of the truck. This display
is evidence of the truck’s
operating time and of the
inspection and maintenance
work to be performed.
If a faulty display unit is
replaced, the operating hours
up to that point must be
recorded. Affix the data on an
embossed strip near the display
unit. There is also the option of
updating the new display unit at
a later time.
(18) Symbol without funct
ion
(19) Clock display (am/pm)
For 12-hour format:
am = morning
pm = afternoon
The diagnostic program can be
used to reset the display to a
12-hour clock.
(20) Symbol without function
(21) Function key
- Adjusting the time
- Scrolling through error
messages
(22) Reset button
- Adjusting the time
- Scrolling through erro
r
messages
- Turning off the warnin
g sound
(23) Time display
24-hour clock displa
y.
Adjustable using the
(21) and
(22) push buttons.
The diagnostic program can be
used to reset the display to a
12-hour clock.
(24)"Do not start the engine"
symbol
- Lights up when the
engine
has stalled. (A blo
ck against
repeat starting is
active and the
engine cannot be st
arted).
Always leave the ignition
switched on until the symbol
goes out.
Then repeat the start attempt.
(25)"Parking brake" symbol
- Lights up if the parking brake
is activated
(26)"Operating hours until the
next service" symbol
After the ignition has been
switched on, display field (17)
shows the operating hours
until the next service (counting
backwards).
Symbol (26) lights up. After
5 seconds, symbol (26) goes
out and display (17) switches
automatically to the truck’s
operating hours; the operating
hours symbol (16) flashes.
(27) Symbol for "Seat belt not
fastened"
(special equipment)
- Lights up if seat belt was not
fastened
Fasten the seat belt
26 Operating Instructions – 394 807 10 01 EN – 07/2011
