LiveU Live Video
Uplink System
User Guide
(
LU60 and LU70)
Version
6.3
Part Number:
DOC00032

Table of Contents

Questions and Answers

  • R
    Rhonda AustinAug 20, 2025
    What to do if the error message "Insufficient Bandwidth for Video Transmission" appears on the LiveU LU60?
    • M
      Michael HernandezAug 20, 2025
      This error appears when the LiveU unit detects that there is less than 128 Kbps free for broadcasting. If your Profile is currently set to Interview, try changing it to the minimum permitted delay using the slider. If your Profile is already set to the minimum permitted delay, try changing it to the maximum permitted delay using the slider. Also, try changing the physical placement of the LiveU TV Tuner unit by moving it closer to a window, where the cellular signal is typically better.
  • K
    Kimberly SchwartzAug 22, 2025
    What to do if the error message "System temperature critical" appears on the LiveU LU60 TV Tuner?
    • R
      Rebecca LuceroAug 22, 2025
      To prevent permanent damage, the system will shut down automatically in five minutes. Please check the air inlets and outlets of your LiveU TV Tuner. Make sure that the air flow path is not obstructed.
  • A
    Anthony AguilarAug 25, 2025
    What to do if the error message "System temperature approaching maximum limit" appears on the LiveU LU60?
    • P
      Paul GarzaAug 25, 2025
      Please check the air inlets and outlets of your LiveU TV Tuner. Make sure that the air flow path is not obstructed.
  • A
    Amber BoydAug 27, 2025
    Why is the audio quality received by the server poor when using the LiveU LU60?
    • M
      Molly GrantAug 27, 2025
      Make sure that the audio sampling of your camera is set to 48 KHz (16 bit).
  • M
    Marie BartlettAug 27, 2025
    How to fix low-quality video results on LiveU LU60 TV Tuner?
    • D
      Debra PruittAug 28, 2025
      Make sure that the correct resolution is selected. Also, make sure that interlacing/deinterlacing is properly defined in both camera and unit (for CIF and VGA). Tap Reconnect on your LiveU TV Tuner. The system should recalibrate itself accordingly, resulting in optimal picture quality. Move the unit closer to a window or outside to improve wireless reception.
  • C
    Carolyn HallAug 30, 2025
    What to do if the Video Resolution on the server's video player does not change despite changes made on the client side of LiveU LU60?
    • A
      Amanda GuzmanAug 30, 2025
      Click Stop and then Start on the LU-1000 server program. The video player should reopen at the correct video resolution.
  • S
    Steven HernandezAug 31, 2025
    What to do if there is no video in the main window and the camera icon is empty/gray on the LiveU LU60 TV Tuner?
    • F
      Frank GrayAug 31, 2025
      Check to see that the camera battery is charged or AC power is connected and that the camera is turned on. Check that the camera is connected properly. If the problem still persists, try to replace the relevant video feed cable. If the problem still persists after trying all the above steps and restarting the system does not resolve the issue, call LiveU support.
  • P
    pamela87Sep 2, 2025
    How to lower the system latency on LiveU LU60?
    • O
      ortizhannahSep 2, 2025
      Tap the Interfaces button and uncheck the modems that have the largest values in the Delay column. Then use the Reconnect button. Note that this may decrease the available bandwidth.
  • M
    Margaret SantosSep 4, 2025
    What to do if LU software is not connecting on LiveU LU60 TV Tuner?
    • R
      Ryan CombsSep 4, 2025
      Make sure that the LU-1000 server is running, awaiting connections and not blocked by any firewalls or NAT routers. Make sure the correct server Channel is selected in the unit. Make sure that the LU-1000 IP and port definitions are identical on both client and server. Verify that the interfaces are active by checking the Interface table.
  • B
    Benjamin MolinaSep 6, 2025
    What to do if the camera is not working with LiveU LU60?
    • C
      Cheryl DuranSep 6, 2025
      Check to see that the camera battery is charged. If the camera seems to be working, make sure that it is correctly connected to the LU via a FireWire (DV) or other cable. Check that the SD/HD settings of both the camera and unit match.

Summary

Overview

System Overview

Describes the LU unit's role in aggregating networks for streaming.

Wireless Connectivity

Explains how the LU connects to cellular, wireless, and Ethernet data infrastructures.

LU Device Types

Details the LU60/LU70 family and their video input options.

What’s in the Box?

Lists the components included in the LU60/LU70 package.

Getting Started

Turning on the LU Device

Procedure for powering on the LU60/LU70 device.

Connecting the Video Camera

Provides instructions for connecting a video camera to the LU unit.

Connecting to the LU-1000

Details the process of connecting the LU unit to the LU-1000 server.

Playing

Instructs on how to start broadcasting live streaming video.

LU User Interface

LU Touch-screen Interface

Details the main LCD touch-screen interface and its elements.

Video Feed

Describes the preview of the video feed displayed on the main window.

Transmission Quality

Explains the indicator for transmission quality and transferred bitrate.

Status Indicator

Explains the status icon indicating connection and transmission status.

Connect;Reconnect Button

Details the process of connecting to interfaces and reconnecting.

Transmit Button

Explains when this button becomes active and how to start broadcasting.

Profiles

Indicates the current operating profile and how to change it.

Successful Video Transmission

Overview

Discusses factors for successful high-quality audio/video stream transmission.

Profiles Window

Explains how to view and select different broadcast profiles.

Changing the Profile

Guides users on how to change the basic broadcast characteristics by selecting a different profile.

Changing a Profile’s Resolution

Explains how to adjust the video resolution for broadcast.

File Transfer

Transferring Files

Guides users on transferring prerecorded files to the LU-1000 server.

Store & Forward

Storing and Forwarding Files

Explains how to record video sessions and forward them to the LU-1000 server.

Configuration and Settings

Configuration Options Button

Access to configuration options like Interfaces, Servers, and Settings.

Interfaces

Describes how to view and configure the LU's modem connections and network interfaces.

Defining a Wi-Fi Interface

Guides users on detecting and connecting to Wi-Fi networks.

Servers

Describes how to define and select LU-1000 server connections.

Media Settings

Allows manual definition of encoding parameters for audio and video.

LU Remote Control

Introducing Remote Control

Explains the purpose of the Remote Control application for remote LU control.

Installing the Remote Control Application

Provides step-by-step instructions for installing the Remote Control application.

Configuring Remote Control

Details the mandatory steps to configure the Remote Control application's connection to the LU-1000 server.

Launching Remote Control

Guides users on how to launch the Remote Control application and log in.

Controlling an LU Remotely

Explains how to select and control an LU device remotely.

What Cannot be Controlled Remotely

Lists functionalities that cannot be controlled remotely via the application.

Troubleshooting

Power Switch LED Not Lighting

Addresses issues where the power switch LED does not illuminate.

Camera Not Working

Troubleshoots scenarios where the camera is connected but not functioning.

LU Software Connection Issues

Solves problems related to the LU software failing to connect.

Low-Quality Video Results

Provides solutions for poor video quality during transmission.

Safety and Maintenance

Safety Information

Provides critical safety instructions and precautions for using the product and battery.

Potential Hazards

Details potential hazards related to operating the unit, especially near explosive atmospheres or interference.
