Logicube Falcon-NEO

GETTING STARTED
Logicube Falcon
®
-Neo User’s Manual 12
A – Operations/Tasks currently running (displays up to 5 total tasks)
B – Lock indicator/shortcut
C – Operations/Tasks
D – Add or delete tasks
E – Types of Operations
F – Up and down scroll arrows
G – Operations options and settings
H – Start icon
2.4 Front and Rear Ports
The Falcon-NEO has two front USB 3.0 ports, an HDMI port, two 10GbE ports, and two DC IN power ports.
2.4.1 Front Ports
The Falcon-NEO has two front USB 3.0 ports. These ports serve two purposes:
 As two additional USB 3.0 Destination ports (USB_D2 and USB_D3).
 To connect peripherals such as USB keyboards and mice.
2.4.2 Rear Ports
The Falcon-NEO has two DC IN power ports, two 10GbE ports, and an HDMI port.
2.4.2.1 DC IN Power Ports
The Falcon-NEO has two DC IN ports. The included AC adapter/power
supply can be connected to either DC IN port and will provide power to
the Falcon-NEO. There are two DC IN ports for possible future power
scaling requirements.
2.4.2.2 Dual 10GbE Ports
The Falcon-NEO has two 10GbE (Gigabit Ethernet) ports (labeled LAN_1
and LAN_2) to provide fast network performance. Some of the possible
uses for these ports include (but are not limited to) the following:
 Connect two NAS devices to each port.
 Connect a NAS to one port and the suspect’s network to the
other.
 Connect a work network (to control the Falcon-NEO remotely)
and a NAS to the other port.
