- 26 -
Explanation of symbols
10.15
2 Explanation of symbols
2.1 Meaning of the symbols in the opera-
tion manual
Danger to life and limb!
If the danger warnings are disregarded,
this can cause slight or severe injuries or
even death.
Danger of property damage!
Disregarding danger warnings can cause
damage to workpieces, tools, and equip-
ment.
General note.
Designates useful information about the
product and equipment
2.2 Meaning of the symbols on the
machine
Danger!
Read the user information in the operation
manual.
Disconnect the mains plug!
Pull out the mains plug before opening the
housing
i
1 Machine elements
10 9 8 7
1 2 3 4 5 6
Abb. 10: Machine elements
1 Mains cable 8 Connector negative pole
2 Mains switch 9 Connector - torch controller
3 Gas connector 10 Air intake
4 Connector remote control
Some depicted or described accessories
are not included in the scope of delivery.
Subject to change.
5 Front panel
6 Shoulder strap
7 Connector positive pole
i
