L-IP User Manual 42 LOYTEC
Version 6.1 LOYTEC electronics GmbH
enabled if group overloading is used in the case that more than 256 group addresses are
needed. Subnet learning is not plug&play. Please use LonMaker, NL-220, or other network
management tools to ensure that one subnet address is only used behind one L-IP port. This
can be achieved by using our L-IP LonMaker shapes or by placing phantom routers in e.g.
NL-220. Please contact LOYTEC support if you think you need this feature!
If the mode is changed via the console menu, it cannot changed via the corresponding DIP
switch anymore (refer to the installation sheet of the product). Choose “[4] Set router
configuration according to DIP switch”, to return control to the DIP switch.
3 - Group learning
This menu option allows enabling or disabling learning of group addresses (see Section
7.1.2).
5 – Block unknown domains
The L-IP will learn up to four domains. If your network contains more than four domains
please contact LOYTEC support for advice!
6 – Factory reset w. status button
In case the L-IP is in the mode repeater or smart switch, pressing the status button longer
than 20 seconds resets the switching tables (see Section 4.5.1). This function can be
disabled using this menu option.
5.6 IP Configuration Menu
The IP configuration menu holds relevant IP settings. Here are some general guidelines for
setting IP addresses, port numbers, and time values:
Enter 0.0.0.0 to clear an IP address.
Enter 0 to select the default port number
Enter 0 to disable a time setting.
Press Return to keep the current setting.
The IP configuration menu when DHCP is disabled is shown in Figure 33.
IP Configuration Menu
=====================
[1] DHCP : disabled
[2] IP Address : 192.168.1.250
[3] IP Netmask : 255.255.255.0
[4] IP Gateway : 192.168.1.1
[5] Hostname : newlip
[6] Domainname : <unset>
[7] DNS Servers : <unset>
[9] MAC Address : 00:0A:B0:01:32:B2 (factory default)
[0] NTP Servers : 0.pool.ntp.org 1.pool.ntp.org (out-of-sync)
[a] Connection Keep Alive : disabled
[b] Link Speed & Duplex : Auto Detect
[q] Quit without saving
[x] Exit and save
Please choose:
Figure 33: IP configuration menu when DHCP is disabled.
The IP configuration menu when DHCP is enabled is shown in Figure 34.
