7-10
 Rotating direction select via –10 ~ +10[V] input of V1 terminal
Group
Code
Parameter Name
Setting
Range
Initial
Unit
Drive group
frq
[Frequency setting]
2
0 ~ 8
0
drv
[Drive mode]
-
0 ~ 4
1
 Set frq to 2.
 Inverter is operating as the table below regardless of Drive mode setting.
FWD RUN Command
REV RUN Command
0 ~ +10 [V]
FWD RUN
REV RUN
-10 ~ 0 [V]
REV RUN
FWD RUN
 Motor runs in Forward direction when input voltage to V1-CM is 0~10[V] and FWD RUN
command is active. When input voltage polarity is reversed to –10~0[V] during FWD RUN, motor
decelerates to stop and runs in reverse direction.
 When input voltage to V1-CM is 0~10[V] and REV RUN command is active, motor runs in
Reverse direction and if -10~0[V] is input, motor rotating direction is reverse.
 FX/RX Run Disable
Group
Code
Parameter Name
Setting
Range
Initial
Unit
Drive group
drC
[Direction of motor
rotation select]
-
F, r
F
Function group 1
F 1
[Forward/Reverse run
disable]
-
0 ~ 2
0
 Select the direction of motor rotation.
 0: Forward and Reverse run enable
 1: Forward run disable
 2: Reverse run disable
