LSIS XBF-AD04A User Manual

Chap. 6 Analog I/O Module (XBF-AH04A)
(2) DC 0 ~ 20mA Range Input
Digital
Output Range
Analog Input Current (mA)
-0.24
0
5
10
15
20
20.23
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(0 ~ 2000)
-24 0 500 1000 1500 2000 2023
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
(3) DC 1 ~ 5V Range Input
Digital
Output Range
Analog Input Voltage (V)
0.96
1
2
3
4
5
5.04
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(100 ~ 500)
96 100 200 300 400 500 504
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
(4) DC 0 ~ 5V Range Input
Digital
Output Range
Analog Input Voltage (V)
-0.06
0
1.25
2.5
3.75
5
5.05
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(0 ~ 500)
-6 0 125 250 375 500 505
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
(5) DC 0 ~ 10V Range Input
Digital
Output Range
Analog Input Voltage (V)
-0.12
0
2.5
5
7.5
10
10.11
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(0 ~ 1000)
-12 0 250 500 750 1000 1011
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
6 - 7
