LSIS XBF-AD04A User Manual

Chapter 10 Analog I/O Option Board (XBO-AH02A)
(3) DC 0 ~ 10V range output
Digital input
range
Analog output voltage (V)
0V or less
0
2.5
5
7.5
10
Over 10V
Unsigned value
(0 ~ 4000)
0 or less 0 1000 2000 3000 4000
Over 4000
Signed value
(-2000 ~ 2000)
-2000 or
less
-2000 -1000 0 1000 2000
Over 2000
Precise value
(0 ~ 2000)
0 or less 0 250 500 750 1000
Over 1000
Percentile value
(0 ~ 1000)
0 or less 0 250 500 750 1000
Over 1000
Note
(1) There is “Dead Band” area around voltage output (0V), current output (0mA).
(a) Digital input-based: about 0 ~ 10
(b) Analog output-based: voltage(about 0 ~ 25 ㎷), current (about 0 ~ 50 ㎂)
(2) In “Dead Band” area, digital input and analog output may not coincide (within accuracy)
10 - 9
