215585 130 Revision A
$
%
Figure 7.3: Driveshield Latch
3. Insert flat end of tool (A) into latch (B) and turn it
counterclockwise to unlock.
$
Figure 7.4: Driveshield
4. Pull top of driveshield (A) away from the header to open.
NOTE:
For improved access, lift the driveshield off the pins at the
base of the shield, and lay the shield on the header.
LUBRICATING THE ROTARY DISC PULL-TYPE
