215585 138 Revision A
8.2 Checking Tire Pressure
Ensure proper inflation of field and optional transport tires.
Figure 8.2: Overinflated Tire
WARNING
• Service tires safely.
• A tire can explode during inflation which could cause serious
injury or death.
$
$
%
Figure 8.3: Field and Transport Wheels
Check tire pressure daily:
• Maximum pressure is 310 kPa (45 psi) for field wheels (A).
• Maximum pressure is 552 kPa (80 psi) for optional transport
wheels (B).
PERFORMING PREDELIVERY CHECKS
